Cov yam ntxwv ntawm lub zog txuag cua txias:
Ø Fin nrug: Lub evaporator muaj 4 qhov sib txawv ntawm qhov sib txawv kom ua tau raws li qhov xav tau cua txias ntawm qhov kub / nruab nrab / qis thiab qhov kub sib txawv.
Series {{0}} fin suab 4.5mm Series 6=fin suab 6.0mm
Series {{0}} fin suab 7.5mm Series 10=fin suab 10.0mm
Ø Kua separator:thiab refrigerant circuit: Lub dispenser thiab tub yees Circuit Court yog optimized los xyuas kom meej efficiency ntawm cov cua txias nyob rau hauv txawv daim ntawv thov ib puag ncig.
Ø Suction gauge kev twb kev txuas: tuaj yeem paub qhov ntsuas qhov ntsuas siab thiab cua txias qhov kev hloov kho.
Ø Ntxuam lub cev muaj zog sib dhos: Tag nrho cov qauv ntawmlub zog txuag cua txiastau nruab nrog cov kev ua haujlwm siab tshiab, kev siv hluav taws xob qis qis nrog kev tiv thaiv thermal sab hauv, tag nrho cov kiv cua yog ob qho tib si sim rau qhov zoo li qub thiab dynamic ntsuas. Lub cev muaj zog lub cev muaj zog cable txuas nrog lub thawv cua txias hleb.
Ø Lub cev muaj zog: φ300mm, φ350mm, φ400mm, ф450mm, ф500mm, ф630mm, ф710mm, φ800mm
Voltage: 1-230V50/60HZ, 3-400V50/60Hz
Rwb thaiv tsev chav kawm: F
Chav kawm tiv thaiv:IP54
Ø Electrical hlws ris Box: Kev tiv thaiv chav kawm: IP67
Ø Hluav taws xob defrosting: Stainless hlau hluav taws xob cua sov raj muab ceev thiab zoo defrosting rau cua txias. Cov khoom cua sov yog txuas nrog lub thawv cua txias hleb. Rau qhov tshwj xeeb, tshwj xeeb tshaj yog hnyav, cov khoom siv rau cov khoom siv loj-load hluav taws xob defrosting ntawm coils thiab cua shrouds tuaj yeem muab.
Ø Kev tu thiab tu:Tsuas yog cov cuab yeej yooj yim tuaj yeem nkag mus rau sab hauv ntawm lub tshuab cua txias, kiv cua npog, sab phaj, thiab cov tais ntim dej yog qhov yooj yim rau disassemble, thiab nws yooj yim rau kev khiav lag luam lub cev muaj zog, cua sov raj thiab expansion valve tom qab disassembly.
Ø Hauv qab ntawm pawg fin yog nruab nrog lub tshuab cua thaiv dej los tiv thaiv cua los ntawm cov dej uas tau txais lub tais, kom cua ntau dhau los ntawm pawg fin thiab tau txais kev sib pauv cua sov ntau dua.
Cua inlet temp | Evaporating temp | TD | Superheat | RH | |
degree | degree | K | K | feem pua | |
SC1 | 10 | 0 | 10 | 6.5 | 85 |
SC2 | 0 | -8 | 8 | 5.2 | 85 |
SC3 | -18 | -25 | 7 | 4.6 | 95 |
SC4 | -25 | -31 | 6 | 3.9 | 95 |
SC5 | -34 | -40 | 6 | 3.9 | 95 |
Cov xwm txheej ua haujlwm:
Refrigerant influence coefficient:
Cov tub yees | Kho qhov tseem ceeb | ||
SC1 | SC2 | SC3 | |
R22 | 0.95 | 0.95 | 0.95 |
R404A | 1 | 1 | 1 |
R507A | 0.97 | 0.97 | 0.97 |
R134A | 0.93 | 0.91 | 0.85 |
Coefficient xa mus rau cov khoom siv fin:
Cov khoom siv Fin | Kho qhov tseem ceeb |
Aluminium | 1 |
Coated aluminium | 0.97 |
Tooj | 1.03 |
